RAHMEN
Aluminium Superlite, Gravity Casting, Agile Ride Geometry, Internal Cable Routing, Full Integrated Battery, Kickstand/Fender/Carrier Mounting Points, 1.5 Headtube (EE: Tapered Headtube)
GRÖSS
Size Split: 27.5: XS (13.5″), S (15″) // 29: M (17″), L (19″), XL (21″), XXL (23″); Easy Entry: XS (46cm), S (50cm), M (54cm), L (58cm)
GABEL
RockShox Judy Silver TK Air, Tapered, 15x110mm, eMTB Approved, 100mm, Lockout
MOTOR
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt)
AKKU
Bosch PowerTube 625
DISPLAY
Bosch Purion
LADEGERÄT
Bosch 2A
BREMSANLAGE
Shimano BR-MT420, Hydr. Disc Brake (203/203) / Size M17: (203/180) / Size XS13.5, S15: Shimano BR-MT420/MT400 (203/180)
SCHALTWERK
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SCHALTHEBEL
Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
KURBELGARNITUR
ACID E-Crank, 175mm, 38T
KASSETTE
Shimano Deore CS-M6100, 10-51T
KETTE
Shimano CN-M6100
VORDERRAD NABE
Shimano HB-MT400-B, 15mm, Boost, Centerlock
HINTERRAD NABE
Shimano FH-MT401, QR, Centerlock
FELGEN
CUBE EX30, 32H, Disc, Tubeless Ready
REIFEN
Schwalbe Smart Sam, Active, K-Guard, 2.6
VORBAU
CUBE Performance Stem E-MTB, 31.8mm, EE: CUBE Comfort Stem Pro, 31.8mm, Adjustable
LENKER
CUBE Rise Trail Bar, 720mm, EE: CUBE Comfort Trail Bar, 720mm
GRIFFE
ACID React Pro (EE: Natural Fit All Terrain)
SATTELSTÜTZE
CUBE Performance Post, 30.9mm
SATTELKLEMME
CUBE Varioclose, 34.9mm
SATTEL
Natural Fit Sequence
STEUERSATZ
M: ACROS AZX-1030, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm) // EE: ACROS AZX-1032, BlockLock 120°, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
PEDALE
ACID PP MTB
GEWICHT
23,3 kg
