RAHMEN
RAHMEN
Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
RAHMEN
RAHMEN
Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing
GRÖSS
Size Split: 27.5: S (15″) // 29″: M (17″), L (19″), XL (21″), XXL (23″); Easy Entry: 27.5: S (16″), M (18″), L (20″), XL (22″)
FAHRWERK
FEDERGABEL
Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm (EE: 100mm)
E-BIKE SYSTEM
MOTOR
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
AKKU
Bosch PowerTube 750
REMOTE
Bosch LED Remote
DISPLAY
Bosch Kiox 300
LADEGERÄT
Bosch 4A
ANTRIEB&BREMSE
BREMSANLAGE
Sram DB8, Hydr. Disc Brake (200/200)
SCHALTWERK
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SCHALTHEBEL
Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
KURBELGARNITUR
ACID E-Crank, 38T, 175mm
KASSETTE
Shimano Deore CS-M6100, 10-51T
KETTE
Shimano CN-M6100
COCKPIT
LENKER
CUBE Rise Trail Bar Pro, 740mm
VORBAU
CUBE Performance Stem E-MTB, 31.8mm
GRIFFE
ACID React Pro / EE: ACID Hybrid Perform
STEUERSATZ
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
LAUFRÄDER
VORDERRAD NABE
Shimano HB-MT400-B, 15mm, Boost, Centerlock
HINTERRAD NABE
Shimano FH-MT410-B, 12mm, Boost, Centerlock
FELGEN
CUBE EX30, 32H, Disc, Tubeless Ready
REIFEN
Schwalbe Smart Sam, Performance, Double Defense, 2.6, Next Gen
AUSSTATTUNG
SATTELSTÜTZE
CUBE Performance Post, 30.9mm
SATTEL
Natural Fit Sequence
PEDALE
ACID PP MTB
SCHEINWERFER
ACID Front Light PRO-E 110, 5-16V, DC
RÜCKLICHT
ACID Mudguard Rear Light PRO-E, 12V, DC
STÄNDER
ACID FM Pure Kickstand
SCHUTZBLECHE
ACID 75 BB-Mount
GLOCKE
Knog Oi
GEPÄCKTRÄGER
M (17″), L (19″), XL (21″), XXL (23″): ACID Gepäckträger Rail. SIC, 29″ Boost; S (15″), EE 16″, EE18″, EE 20″, EE22″: ACID Gepäckträger Rail. SIC, 27,5″ Boost
ARTIKELINFORMATIONEN
GEWICHT
25,9 kg
